AUXILIARY TRANSFORMER NO. 2 REMOVAL AND
REPLACEMENT PROCEDURE (continued)
REPLACEMENT PROCEDURE
1. Carefully place the transformer into the V450-
PRO.
2. Install the two mounting screws that hold the
transformer to the machine base using the 3/8”
nut driver.
3. Connect plugs P50, P51 and P52.
4. Connect any leads and install cable ties as nec-
essary.
5. Install the case back using the 3/8” nut driver.
6. Install the case top, sides, and input access
panel using the 3/8” nut driver.
TROUBLESHOOTING AND REPAIR F-69 F-69
INVERTEC® V450-PRO
