MAINTENANCE D-3 D-3
INVERTEC® V450-PRO
1. Case Front Assembly
2. Control Box & Horizontal Plate
3. Base, Lift Bale & Fan Assembly
4. Input Assembly
5. Transformer & Output Assembly
6. Switch Board Heatsink Assembly
7. Covers Assembly
Figure D.1 - Major Component Location
5 5 1 1 7 7 4 4 3 3 6 6 2 2
5 5
1 1
7 7
4 4
3 3
6 6
2 2
