E10
NAC 282 Preamplifier
11.4 NAC 282 Connected to Hi-Cap and NAPSC
mains input
and fuse
to stereo power amplifiers
to mono or dual
mono power
amplifiers
additional
signal out-
put
cable
direction
marker
240° 5 to 5 pin DIN
Interconnect Cables
12 NAC 282 Specification
Input Sensitivities:
75mV, 47kΩ
Overload Margins:
40dB
(all inputs all audio frequencies)
Main Output Level:
0.775V, <50Ω
Tape Output Level:
75mV, 600Ω
Auxiliary Power Outputs:
For Naim phono stage.
Dimensions (H x W x D):
87 x 432 x 314mm
Weight:
7.0kg
Mains Supply (Hi-Cap):
100V, 115V or 230V, 50/60Hz
Note:
Alternative upgrade schemes and product
combinations may be feasible. Contact your local
representative or Naim Audio directly for further information.
