E16
17.4 NAC 152 XS Connected to Hi-Cap and FlatCap XS Power Supplies (stage 2 upgrade)
mains input
and fuse
power
switch
for CD5 XS, Headline or
phono stage. Additional
interconnects required.
NAC 152 XS Preamplifier
18 NAC 152 XS Specification
Input Sensitivities:
130mV, 47kΩ
Overload Margins:
35dB
(all inputs all audio frequencies)
Main Output Level:
0.775V, <50Ω
Line Output Level:
130mV, 600Ω
Auxiliary Power Outputs:
For Naim phono stage.
Dimensions (H x W x D):
70 x 432 x 301mm
Weight:
3.9kg
Mains Supply (FlatCap XS):
100V, 115V or 230V, 50/60Hz
mains input
and fuse
to stereo power amplifiers
to mono or dual
mono power
amplifiers
additional
signal output
cable
direction
marker
4 to 4 pin DIN
Interconnect Cables
240° 5 to 5 pin DIN
