E21
20.5 SUPERNAIT Connected to Hi-Cap Power Supply and NAP 200 Power Amplifier
mains input
and fuse
cable
direction
marker
4 to 4 pin DIN
Interconnect Cables
240° 5 to 5 pin DIN
mains input
and fuse
SUPERNAIT Integrated Amplifier
21 SUPERNAIT Specification
Input Sensitivities:
75mV, 47kΩ
Overload Margins:
40dB
(all inputs all audio frequencies)
Preamp Output Level:
0.775V, <50Ω
Tape Output Level:
75mV, 600Ω
Power Output:
Continuous 80 Watts per
channel into 8 Ohms
Auxiliary Power Outputs:
For Naim phono stage
Quiescent Consumption:
10VA
Dimensions (H x W x D):
87 x 432 x 314mm
Weight:
12.8kg
Mains Supply:
100V, 115V or 230V, 50/60Hz
mains
input
and fuse
power
