R-com Remote Handset
29 R-com Remote Handset
The R-com remote handset is supplied with the NAC 552 and CD555 and can be
purchased as an accessory. It offers quick and intuitive control of the most often used
functions of CD players, preamplifiers, integrated amplifiers and tuners.
To fit batteries, remove the bottom end cover using the tool provided and insert the
batteries into the body taking care with their orientation. Replace the end cover. Remove
the batteries if the R-com is to be packed and shipped.
29.2 R-com Keys
play stop
prev next
vol +
pause
vol -
mute
open
tun
disp
pre
29.1 Using R-com
R-com keys primarily provide control of the functions
most often used on CD players, preamplifiers, integrated
amplifiers and tuners. In order to extend battery life, R-com
will enter a “sleep” mode when unused. It will “wake” on
being touched.
R-com has three operational modes - CD Player mode,
Preamplifier/Integrated amplifier mode and Tuner mode. Its
default mode is CD player. When awake in CD Player mode,
all R-com keys will illuminate green. To switch the R-com into
Preamplifier/Integrated amplifier mode or Tuner mode press
the
pre or tun keys respectively. The pre or tun key will then
illuminate white. To switch R-com back into CD player mode
either press the
pre or tun key again.
In default mode the R-com keys have the following
functions:
disp: Scrolls through the display options of track, time
and display off.
open: Opens the door on the CD555.
stop: Stops CD replay.
play: Begins CD replay.
prev: Selects the previous track or index point.
next: Selects the next track or index point.
vol +: Increases the preamplifier/integrated amplifier
volume.
vol –: Decreases the preamplifier/integrated amplifier
volume.
mute: Reduces the volume to zero. A second press
restores the volume.
pause: Pauses CD replay. A second press restores play.
In Preamplifier/Integrated amplifier mode (press pre key),
the following keys will change function:
disp: Switches the preamplifier/integrated amplifier front
panel button indicators & knob indicators off and on.
prev: Selects the previous source input.
next: Selects the next source input.
Note: Preamplifier or integrated amplifier program mode
can be selected from the R-com by pressing and holding
the pre key. Program mode functions can then be
accessed from the equipment front panel.
In Tuner mode (press tun key) the following keys will change
function:
disp: Switches the tuner display and front panel button
indicators off and on.
prev: Selects the tuner “down” function.
next: Selects the tuner “up” function.
Note: Tuner modes can be selected from the R-com by an
extended press of the tun key.
