NAC 152 XS Preamplifier
16 NAC 152 XS Introduction and Installation
The NAC 152 XS preamplifier does not incorporate an internal power supply but must be
used in conjunction with either a Naim power amplifier incorporating a preamplifier power
output, or with an appropriate Naim power supply. Diagram 17.3 illustrates the NAC 152 XS
connected to a FlatCap XS power supply.
The preamplifier and any power supply should be installed on a dedicated equipment
stand intended for the purpose. Do not stand either preamplifier or power supply directly
on top of another item of equipment. Ensure that the preamplifier is level.
The preamplifier and any power supply should be installed in their final locations before
connecting cables or switching on. Ensure that the preamplifier volume is turned down
before switching on.
The following Section 16 paragraphs describe installation features and functions specific
to the NAC 152 XS. Operational features common to all preamplifiers and integrated
amplifiers are described in Section 28.
16.1 Audio Inputs
The input selection buttons select the source input signal
to be routed to the preamplifier outputs and the power
amplifier.
The NAC 152 XS has six DIN input sockets and five pairs
of RCA Phono sockets. The RCA Phono sockets are
permanently connected in parallel with their respective DIN
sockets. RCA Phono and DIN sockets for the same input
should not be connected simultaneously.
Note: The aux2 DIN input socket carries a power supply
output voltage appropriate for a Naim phono preamplifier.
A 3.5mm stereo Jack input socket suitable for an iPod (or
alternative portable music player) is also provided on the
NAC 152 XS front panel. This input is connected in parallel
with the aux 1 DIN and RCA Phono sockets.
Insertion of a plug into the front panel socket will
automatically switch the preamplifier to that input. Removal
of the plug will return the amplifier to the previously selected
input. If a different input is selected while a plug is inserted,
removal of the plug will not cause the input to change.
16.2 Audio Outputs
The NAC 152 XS provides subwoofer and line level outputs,
each via a pair of RCA Phono sockets.
The line level output simply reflects the selected input signal
while the subwoofer output is a duplicate of the main
preamplifier output (i.e it is affected by the preamplifier
volume control).
16.3 Power Supply Upgrades
The NAC 152 XS can be powered by a Naim power
amplifier incorporating a preamplifier power supply or its
performance upgraded through the connection of one or
more external power supplies. Power supply upgrades can
be carried out in stages:
Stage 1 is to connect an i-Supply , Flatcap, Hi-Cap or
Supercap power supply to the NAC 152 XS Upgrade 1
socket. The link/blanking plug inserted in the Link 1 socket
must be removed.
Stage 2 is to connect a Flatcap, Hi-Cap or Supercap power
supply to the NAC 152 XS Upgrade 2 socket. The link plug
fitted to this socket must be removed. With a second power
supply added, the NAC 152 XS no longer requires a power
supply from the power amplifier, which should now be
connected via the Stage 2 power supply.
Diagrams illustrating both power supply upgrade stages are
shown in Section 17.
Note: Link plugs must only be inserted in the sockets from
which they were removed and unused power supply
sockets must not be used for any other purpose. Incorrect
use of link plugs and power supply sockets risks significant
damage to the power supply or preamplifier.
Note: A wide variety of different power supply schemes are
potentially possible for the NAC 152 XS, including the use of
one Flatcap for both upgrade stages. Your local retailer will
be able to advise on the best scheme for your particular
system.
Note: The NAPSC power supply cannot be used with the
NAC 152 XS.
Operational features
common to all
preamplifiers and
integrated amplifiers
are described in
Section 28
