E35
34.1 General Connections Notes
The negative input and output connections for each
channel are common. The mains earth (ground) should
always be connected regardless of what other equipment
is used in conjunction with Naim power amplifiers. This only
grounds the case and the electrostatic screen within the
transformer, and is not connected to the signal negative. In
order to avoid hum loops, the signal negative of the whole
system should be connected to the mains earth (ground)
in one place.
34.2 Protection Notes
In the NAP 300 the fan speed is increased in response to an
increase in amplifier dissipation. If the amplifier reaches 70°C
due to prolonged running at high level or to airflow being
blocked, the output will be interrupted and the fan will run
at full speed until it has cooled down. This may take a few
minutes.
It is not necessary to switch the amplifier off, but it may be
advisable to mute the preamplifier or turn the volume down
to avoid surprises when it comes back on.
OPERATION OF THE AMPLIFIER’S THERMAL PROTECTION
SUGGESTS PROLONGED USE AT TOO HIGH A VOLUME LEVEL.
YOUR LOUDSPEAKERS MAY BE AT RISK IF THIS IS THE CASE.
THE VOLUME SHOULD BE REDUCED.
34 Installation and Operation
The NAP 300 and NAP 300PS should be installed on a dedicated equipment stand
intended for the purpose and should be in their final location before connecting cables or
switching on. Switch on the source and preamplifier components, with the volume turned
down, before switching on the NAP 300. The NAP 300 power button is located on the front
panel of the NAP 300PS Power Supply.
Care should be taken when siting the NAP 300 to ensure that the underside fan inlet and
rear outlet are not obstructed.
The NAP 300 and NAP 300PS are heavy and care should be taken when lifting or moving
them. Make sure that the surface they are to be placed on can support the full weight.
34.3 Loudspeaker Cable and Connectors
Only Naim Audio speaker cable should be used to connect
a loudspeaker to the output of the NAP 300. Custom Naim
Audio loudspeaker connectors are supplied to make the
connection and in order to comply with current European
safety regulations these should always be used.
DAMAGE TO THE AMPLIFIER MAY RESULT IF “HIGH
DEFINITION” CABLE OR ANY OTHER SPECIAL CABLE IS USED
TO CONNECT THE LOUDSPEAKERS.
Ensure when connecting speakers that they are “in phase”.
That is, the positive and negative connection orientation
at both the speaker and amplifier ends of the cable is the
same for both channels.
NAP 300 Power Amplifier
