Chapter 2: Board Components

2–5

Board Overview

May 2014

Altera Corporation

Transceiver Signal Integrity Development Kit

Stratix V GT Edition Reference Manual

Memory Devices

U21

Flash memory

Micron PC28F00AP30BF, 1-Gb CFI NOR flash memory.

U17

EEPROM

Microchip Technology Inc. 93LC46B/SNG-ND, 64x16 EEPROM SO.

Communication Ports

J29

Gigabit Ethernet port

RJ-45 connector which provides a 10/100/1000 Ethernet connection
through a Marvell 88E1111 PHY and the FPGA-based Altera Triple
Speed Ethernet MAC MegaCore function in SGMII mode.

J93

JTAG header

Connects an Altera USB-Blaster dongle to program the FPGA and
MAX II CPLD devices. The embedded USB-Blaster is disabled when
you connect the USB-Blaster to the JTAG header.

CN1

USB Type-B connector

Connects a type-B USB cable to enable the JTAG embedded
USB-Blaster to program the FPGA and MAX II CPLD devices.

Power Supply

J1

DC input jack

14-V – 20-V DC female input power jack. Accepts a 2.5-mm male
center-positive barrel from 14-V DC power supply.

SW1

Power switch

Switch to power on/off the board.

J6

S5GX_VCC (0.85 V/0.9 V)
banana jack

Banana jack for supplying external V

CC

power to the FPGA. Fuses F1

and F2 must be removed prior to supplying external power to this
banana jack.

J12

VCCA_GXB (2.5 V/3.3 V)
banana jack

Banana jack for supplying external V

CCA

power to the FPGA. Fuse F7

must be removed prior to supplying external power to this banana jack.

J9

VCCRT_GXB (0.85 V/1.0 V)
banana jack

Banana jack for supplying external V

CCRT_GXB

power to the FPGA. Fuse F6

must be removed prior to supplying external power to this banana jack.

J15

VCCR_GTB (1.0 V) banana
jack

Banana jack for supplying external V

CCR_GTB

power to the FPGA. Fuse F3

must be removed prior to supplying external power to this banana jack.

J21

VCCL_GTB (1.0 V) banana
jack

Banana jack for supplying external V

CCL_GTB

power to the FPGA. Fuse F5

must be removed prior to supplying external power to this banana jack.

J18

VCCT_GTB (1.0 V) banana
jack

Banana jack for supplying external V

CCT_GTB

power to the FPGA. Fuse F4

must be removed prior to supplying external power to this banana jack.

J3

Ground banana jack

Banana jack connected to ground.

U10 and U11

Power monitor devices

Linear Technology LTC2978, octal PMBus power supply monitor and
controller.

Table 2–1. Transceiver Signal Integrity Development Kit Components (Part 4 of 4)

Board Reference

Type

Description
