Chapter 2: Board Components 2–31
General User Input/Output
May 2014 Altera Corporation Transceiver Signal Integrity Development Kit
Stratix V GT Edition Reference Manual
Table 2–29 shows the LCD pin definitions, and is an excerpt from the Lumex data
sheet.
f For more information such as timing, character maps, interface guidelines, and other
related documentation, visit
www.lumex.com .
Table 2–30 lists the LCD component references and the manufacturing information.
Table 2–29. LCD Pin Definitions and Functions
Pin
Number
Symbol
Level
Function
1 V
DD
—
Power supply
5 V
2 V
SS
— GND (0 V)
3 V
0
— For LCD drive
4 RS H/L
Register select signal
H: Data input
L: Instruction input
5 R/W H/L
H: Data read (module to MPU)
L: Data write (MPU to module)
6 E H, H to L Enable
7–14 DB0–DB7 H/L Data bus, software selectable 4-bit or 8-bit mode
Table 2–30. LCD Component References and Manufacturing Information
Board
Reference
Description Manufacturer
Manufacturer
Part Number
Manufacturer
Website
J30
2×7 pin, 100 mil, vertical header Samtec TSM-107-01-G-DV www.samtec.com
2×16 character display, 5×8 dot
matrix
Lumex Inc. LCM-S01602DSR/C www.lumex.com
