10.
EXTERNAL CONNECTIONS
10.1 Alarm Connector
This connector allows access to the contacts of the alarm relay contained within
the MICROTHERM control unit.
The connector is wired thus:
Common
contact
Normally
closed contact
Normally
open contact
Set 1
Pin 2
Pin 6
Pin 1
Set 2
Pin 4
Pin 5
Pin 3
The contacts are rated at 1 A resistive at 24 V and are voltage free.
