ZAS Hbb
Synchronization and channel
Input
connector
. . . . . . . . . . . . . . . . . . . . . . 1
x
CEI (female)
Output
connector
. . . . . . . . . . . . . . . . . . . . 1
x
CEI (male)
Input
frequency
. . . . . . . . . . . . . . . . . . . . . .
174 MHz to 862 MHz
Frequency input link . . . . . . . . . . . . . . . . . .
147 MHz to 862 MHz
Signal level . . . . . . . . . . . . . . . . . . . . . . . . . . .
45 to 90 dBμV
Input
impedance
. . . . . . . . . . . . . . . . . . . . . 75
Ohm
RF channel bandwidth . . . . . . . . . . . . . . . .
7/8 MHz
Demodulation
. . . . . . . . . . . . . . . . . . . . . . . . COFDM
Transmission
mode
. . . . . . . . . . . . . . . . . . .
2K FFT, 8K FFT
Constellations
. . . . . . . . . . . . . . . . . . . . . . . . . 16QAM,
64QAM
FEC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1/2, 2/3, 3/4, 5/6, 7/8
Stand-by
interval
. . . . . . . . . . . . . . . . . . . . .
1/4, 1/8, 1/16, 1/32
Digital video
Compatible with . . . . . . . . . . . . . . . . . . . . . .
MPEG-2 and MPEG-4/H.264
Profile and level . . . . . . . . . . . . . . . . . . . . . .
MPEG-2 MP@HL, MPEG-4.2 ASP@L5, MPEG-4.10 (H.264) BP@L3, [email protected]
and [email protected]
Video bit Rate . . . . . . . . . . . . . . . . . . . . . . . . 40
Mbit/s Max.
format
. . . . . . . . . . . . . . . . . . . . . . . . .
4:3, 16:9
Video resolution . . . . . . . . . . . . . . . . . . . . . .
1080p, 1080i, 720p, 576p, 576i
Audio
Audio decoder . . . . . . . . . . . . . . . . . . . . . . . .
MPEG-1 Layers I, II and III, AAC, HE-AAC, Dolby Digital, Dolby Digital+
Teletext . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compatible with DVB
Memory
Flash
Memory
. . . . . . . . . . . . . . . . . . . . . . . .
4Gbit NAND Flash
RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 x 2Gbit DDR2 SDRAM
Input/output A/V
Scart TV x 1:
- Video output RGB . . . . . . . . . . . . . . . . . . . . 1
x
socket Scart TV
- Video output CVBS . . . . . . . . . . . . . . . . . . 1
x
socket Scart TV
- Analogical audio output . . . . . . . . . . . . . 1
x
socket Scart TV
Optical
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optical (TOSLINK)
HDMI
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Digital Video/Audio output
LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Gbit Ethernet - RJ45
Multimedia format
Video
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MP4, MKV, AVI, MPEG, TS
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MP3
Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
JPEG
Power supply
Input voltage . . . . . . . . . . . . . . . . . . . . . . . . . 12
V.
DC
Type
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC
adapter (230 V, 50/60 Hz.)
Max electrical consumption . . . . . . . . . . .
480 mA
Max Stand-by consumption . . . . . . . . . . . 80
mA
Physical specifications
Dimensions (L x H x D) . . . . . . . . . . . . . . . . .
180 mm x 29 mm x 130 mm
Approx
weight
. . . . . . . . . . . . . . . . . . . . . . . .
300 gms
Environmental specifications
Operating temperature range . . . . . . . . . From
-5ºC to 45ºC
Technical Characteristics
