Condition Switch
1
Up
2
Up
3
Up
4
Down
5
Up
Mode Switch
1
Up
2
Up
Output∗ only when bus and line input voltages are less than 30 volts.
Condition Switch
1
Up
2
Up
3
Up
4
Up
5
Down
Mode Switch
1
Up
2
Up
Output∗ only when bus and line input voltages are greater than 80 volts.
Condition Switch
1
Up
2
Down†
3
Up
4
Up
5
Up
Mode Switch
1
Up
2
Up
∗
Contact is SYNC output for output option E or F. Voltage Monitor output for output option G or H.
† The only valid use for the LB-LL Condition Switch No. 2 Down is when there is an independent output
relay for the Voltage Monitor output options G and H.
If the delta voltage option is present, it is factory set to 20 volts. (The timed SYNC output is inhibited if the
voltage difference between the line and the bus is greater than 20 volts.)
CAUTION
Condition Switch No. 2, shown in Figure 2-2, must be OFF (Up) when output
option E or F is selected. Otherwise, SYNC outputs will occur under live line/live
bus conditions without benefit of the Sync-Check function.
