5
99
exit RAID bIoS
1. Take TryRAID5 as an example, select “ 5. exit” in main menu and press <Enter>.
The screen displays :
2. Press <Y> to exit Intel ® Matrix Storage Manager program. The system will enter
BIOS setup.
3. Shut down the computer, remove the Non-RAID disk, and we will continue for
Windows OS installation. If you do not remove irrelevant hard disk, Windows may
detect it during the installation, and you could �e confused.
4. Remove any diskette from floppy drive.
5. Restart computer to start Windows installation.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Recover Volume Options
RAID Volume :
ID Name Level Stripe Size Status Boota�le
0 TryRAID5 RAID5(Parity) 64KB 149.1GB 0 TryRAID5 RAID5(Parity) 64KB 149.1GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 Hitachi HDS72161 PVF904�21G2J�M 149.0GB Hitachi HDS72161 PVF904�21G2J�M 149.0GB PVF904�21G2J�M 149.0GB Member Disk(0)
1 ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
2 SAMSUNG HD1�1HJ S0V3J9APA30524 149.0GB S0V3J9APA30524 149.0GB 149.0GB Member Disk(0)
3 ST380815AS 5RW1CA37 74.5GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ DISK/VOLUME INFORMATION ]
[ MAIN MENU ]
5. Exit
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Are you sure you want to exit? (Y/N):
[ CONFIRM EXIT ]
