Health
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
Case Open Warning [�isabled]
CPU Temperature : +19 C
System Temperature : +30 C
CPU Fan Speed : 2008 RPM
System Fan 1 Speed : N/A
CPU Vcore : +0.972 V
�RAM Voltage : +1.608 V
+12V SYS : +11.971 V
+5V SYS : +3.002 V
VBAT : +3.120 V
Smart Fan Function [�isabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Exit
ESC: Exit
Case Open Warning
Health
► Case Open Warning
This item is used to ena�le or disa�le case open warning function.
► CPU Temperature
These items show the current CPU temperature detected automatically �y the system.
► System Temperature
These items show the current System temperature detected automatically �y the system.
► CPU Fan Speed
This item shows the current CPU Fan speed detected automatically �y the system.
► System Fan 1 Speed
This item shows the current North Bridge Fan speed detected automatically �y the system.
► CPU Vcore/DRAM Voltage/+12V SYS/+5V SYS/VBAT
These items show the Current CPU Ccore/DRAM/+12V SYS/+5V SYS/VBAt voltage detected
automatically �y the system.
► Smart Fan Function
This option is used to ena�le or disa�le smart fan function. Default value is [Disa�led].
