Chipset
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Power Health Security Save & Exit
▶ North Bridge
▶ ME Subsystem
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Exit
ESC: Exit
North Bridge Parameters
Chipset
► North Bridge/ME Subsystem
Press <Enter> to go to its su�menu.
North Bridge
Version 2.02.1205. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Memory Information
Total Memory 1024 MB (��R3 1333)
Memory Slot1 0 MB (��R3 1333)
Memory Slot2 1024 MB (��R3 1333)
Memory Slot3 0 MB (��R3 1333)
Memory Slot4 0 MB (��R3 1333)
VT-d [�isabled]
Initate Graphic Adapter [PEG/IG�]
IG� Memory [64M]
IG� Multi-Monitor [�isabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized �efaults
F4: Save & Exit
ESC: Exit
Low MMIO resources align at
64MB/1024MB
Chipset
► Total Memory
This item displays the current using memory information.
► Memory Slot 1/2/3/4
These items display the memory size installed on each slot.
► VT-d
