4. It then goes to “ Disks” item. Press <Enter> to display the hard disks list for this RAID0
system.
5. From the hard drive list, use Up or Down arrow key to reach the hard disks you want
to combine them as RAID0, then press <Space> key to select them. A triangle sign
will appear to indicate the drive selected. Here, we select two 149.0GB hard disks as
an example. Press <Enter> key to finish the selection.
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Name:
RAID Level:
TryRAID0
RAID0(Stripe)
Port Drive Model Serial # Size Status
► 0 Hitachi HDS721616PLA Hitachi HDS721616PLA PVF904�21G2J�M 149.0GB Non-RAID Disk
11 ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk Non-RAID Disk Non-RAID Disk
► 2 SAMSUNG HD1�1HJ S0V3J9APA30524 149.0GB Non-RAID Disk 149.0GB Non-RAID Disk Non-RAID Disk Non-RAID Disk
33 ST380815AS 5RW1CA37 74.5GB Non-RAID Disk Non-RAID Disk
Select 2 to 6 disks to use in creating the volume.
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
2 SAMSUNG HD161HJ S0V3J9APA30524 149.0GB Non-RAID Disk
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
[ CREATE VOLUME MENU ]
[ SELECT DISKS ]
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Intel(R) Rapid Storage Technology - Option ROM - 10.0.0.1032
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
Name:
RAID Level:
TryRAID0
RAID0(Stripe)
Port Drive Model Serial # Size Status
0 Hitachi HDS721616PLA Hitachi HDS721616PLA PVF904�21G2J�M 149.0GB Non-RAID Disk
11 ST380811AS 5PS1TAGW 74.5GB Non-RAID Disk Non-RAID Disk Non-RAID Disk
22 SAMSUNG HD1�1HJ S0V3J9APA30524 149.0GB Non-RAID Disk 149.0GB Non-RAID Disk Non-RAID Disk Non-RAID Disk
33 ST380815AS 5RW1CA37 74.5GB Non-RAID Disk Non-RAID Disk
Select 2 to 6 disks to use in creating the volume.
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
[ SELECT DISKS ]
0 Hitachi HDS721616PLA PVF904�21G2J�M 149.0GB Non-RAID Disk
[ CREATE VOLUME MENU ]
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
