RP620 Power Vent Indoor Gas Fireplace
Page 15
XG0777 - 122014.1
Installation
Framing for Rear Vent, Vertical Vent Run installations:
Firestop Require
when penitrating
ceilings
96"
2438
Min
52 12 "
1334
Max
36 12 "
927
Min
Chase
Ceiling
Platform
Chase Constuction
Rear Vent with Vertical Vent
Figure 7b. Framing the unit - Rear Vent, Vertical Vent Run
