Installation

Venting components

Montigo supplies a variety of power venting options. The location

of the power vent should be selected and laid out to provide the

most efficient possible run to an external wall or through the roof.
Notes For Planning Venting:

■ RP-Series fireplaces are Power Vent Designated and use

....

Montigo's 5/8 vent pipes.
■ Venting originates from the top or rear of the unit.
■ Venting can terminate through the roof or exterior wall.
■ For a detailed diagram of allowed termination locations, see

pages 22, 24, or 26.

■ Once the termination location has been established refer to

the appropriate section for installation details.
■ All fireplaces are shipped Top Vent from the factory.
■ Ensure there is a minimum vent run of

2' of straight vent pipe

before the power vent, except for straight rear vented installs.

Follow the chart on

page 20 for maximum vent run and

maximum elbows.

The following components and associated Montigo part numbers

are for installation of a roof or wall mounted Power Vent.

Only use

Montigo Vent Components. Use of non-Montigo parts will VOID

the warranty and may impede operation of the fireplace.

A - Termination with

Frame Kit

PVVEX58-300 (Roof Mount 5"/8")

PVHEX58-300 (Wall Mount 5"/8")

PVHFL58-300 (Flush Wall Mount 5"/8")

PVHIN58-300 Inline Power Vent with

TMHIN58-40 termination

B - Flex Sections

PFL1 (12" f/f Section)

PFL2 (24" f/f Section)

PFL3 (36" f/f Section)

PFL4 (48" f/f Section)

PFL6 (72" f/f Section)

C - Rigid Sections

PXT - 10 (10" f/f Section)

PXT - 20 (20" f/f Section)

PEXT - 1 (12" f/m Section)

PEXT - 2 (24" f/m Section)

PEXT - 3 (36" f/m Section)

PEXT - 4 (48" f/m Section)

PEXT - 6 (72" f/m Section)

D - Elbows

PEL-90MM (m/m 90º Elbow)

PEL-90FF ( f/f 90º Elbow)

PEL-90FM ( f/m 90º Elbow)

PEL-45FM ( f/m 45º Elbow)

E - Support Ring & Plate RSPXT-8
F - Firestop

FS-8

G - Heat Shield

RHS101

Connection and installation of the vent components should

adhere to the following guidelines:

„

Montigo recommends the use of a flex section for the final pipe

connected directly to the fireplace offering greater flexibility

of installation and absorption of movement.

„

Firestops must be installed as required by National & local

codes.

„

When passing vent pipe through a wall use a heat shield.

„

Montigo recommends that all exterior corners and joints be

sealed with exterior caulking. However, we encourage you

to consult your Building Envelope Engineer or Waterproofing

Consultant for further recommendations.

„

Use any combination of rigid and flex pipe as required and in

any orientation (Male connectors can face in any direction).

„

Flex sections may be stretched up to 50% of their total length

(e.g. a 24” section maybe stretched to 36”).

„

Ensure the pipe ends male to female slide in a minimum of

1 1/2” of overlap.

„

Connect all vent sections using a minimum of three sheet

metal screws on the outer pipe flue.

„

Ensure all runs are supported with a minimum of 3 supports

per 10’ of venting.

„

When hanging/ supporting venting, ensure that 1” clearance

is maintained on sides and bottom of vent runs and 2” above

horizontal vent runs to any combustible material.

„

Rigid pipe may be cut less than half way from the

female

end only.

„

Ensure when cutting sections of rigid pipe to maintain integrity

of internal supports.

„

Place the springs, supplied with the pipe kit, between the

outer and inner pipes to keep the pipes separate and avoid

any possible hot spots.

IMPORTANT:

Please Refer to your Building Envelope

Engineer or Waterproofing Consultant

for a review of ALL penetrations through

exterior walls or the roof.
