RP620 Power Vent Indoor Gas Fireplace
Page 33
XG0777 - 122014.1
Installation
Inner Window:
Follow the steps to remove, or install the RP620* fireplace window.
Step 1:
Remove glass suction cups from box and place on Glass panel. (The
tool may not be exactly as shown).
Step 2:
Place the suction cups on the outer glass panel, spaced evenly.
(Ensure they are firmly attached, and secured.)
Step 3: Lifting the glass panel.
Hold the Tools firmly and lift the glass panel up and out of the lower
track (Into the upper track). Tilt the lower edge of the glass panel
outwards.
Step 4:
Ensure the top edge of the glass panel is fully removed from the
upper outer track. Then tilt and lift away cautiously from the fireplace.
Store in a safe location.
Step 5:
Attach suction cups on the inner glass door. Remove the four inner
glass retainers at the top of the glass, see figure for glass retainer
placement.
Caution: keep at least one hand on suction cup attached to the inner
glass when removing the last glass retainer. Glass could fall forward
and break if not secure.
Step 6:
Lean the inner glass door towards you from the top of the glass. Lift
inner glass door up and out. Be careful not to impact the glass door
against metal as it could cause the glass to chip.
Figure 25.
Figure 26.
Figure 27.
Figure 28.
Figure 29.
Figure 30.
