RP620 Power Vent Indoor Gas Fireplace

Page 7

XG0777 - 122014.1

Installation

Install location:
The RP-Series fireplace may be installed in any location that

maintains proper clearances to air conditioning ducts, electrical

wiring, and plumbing. Safety, as well as efficiency of operation,

must be considered when selecting the fireplace location. Try

to select a location that does not interfere with room traffic,

has adequate ventilation, and offers an accessible pathway for

Power Vent installation.

Basic Operation:
The gas control components of this fireplace are located in the

bottom of the firebox below the burner system. All models are

supplied with a Honeywell smart valve gas control and do

NOT

have a variable flame control. A differential pressure switch

is located at the bottom of the firebox monitors airflow and

controls the gas valve. A thermal switch located on the top of

the firebox acts as a secondary safety system and shuts down

the fireplace in the event that normal operating temperatures

exceeded. These components communicate with the electrical

control panel through a six conductor cable supplied with the

fireplace.
To operate the fireplace, Montigo supplies 20' of low voltage

wire from the electrical control panel. Connect the two wire

harnesses to a standard single pole ON/OFF switch to the

location of your choice. You may extend these wires up to 100'

in length with a wire of equal quality.
This fireplace is equipped with lights which need to be wired

through a wall switch or dimmer circuit as shown in the

schematic.
ON/OFF control of this appliance can also be performed using

an optional remote control available from your Montigo dealer.

Installation Sequence
■ Unpacking and set-up
■ Framing
■ Fireplace placement and securing
■ Power connection
■ Gas connection
■ Power vent termination installation.
■ Vent installation.
■ Test firing.
■ Steel framing.
■ Wall boarding / finishing
■ Installation of windows / accessories

Installation and repairs should be done by a qualified contractor

and must conform to:

Installations in Canada must conform to the local codes or

in the absence of local codes to the current version of Natural Gas

and Propane Installation Code, CSA B149. Electrical Installations

must conform to the local codes or, in the absence of local codes,

to the current version of Canadian Electrical Code, CSA C22.1.1

Installations in the USA must conform to the local codes

or in the absence of local codes to the current version of National

Fuel Gas Code, ANSI Z223.1/NFPA 54. Electrical Installations must

conform to the local codes or, in the absence of local codes, to the

current version of the National Electrical Code, ANSI/NFPA 70.

See

Appendix B for installation within the State of Massachusetts.

Fuel Type

Verify that your fireplace is compatible with your available gas

type. Natural Gas or Propane shown by "N" or "L" in your model

number on rating plate.
