Installation
Step 3:
Remove the trim from the bottom of the door as shown.
Step 4:
Remove the other side, as shown in Steps 1 - 3.
Removing the outer window:
Step 2:
Then, pull the trim from the top of the door, as shown.
Section 9: Removing / Installing the Safety Screen and Inner/Outer Windows
Figure 22.
Removing the screen:
There are two tabs located at either end of the screen bottom. By
grasping these tabs lift the screen upward into the upper track. Once
the screen has cleared the boom track, pull the bottom of the screen
away and downwards from the unit to remove the screen from the
upper track.
Figure 22a.
Step 1:
Grasp the trim on either side of the door with the tips of your fingers.
(Both sides Typ.) Pull firmly to remove the trim from the fireplace.
Figure 23.
Figure 24.
