Montigo RP620 - Manual (Page 41)

RP620 Power Vent Indoor Gas Fireplace
Page 41
XG0777 - 122014.1
Maintenance
General
■
Have the fireplace and installation inspected yearly. The
inspection must include, but is not limited to, the following:
• A visual check of the entire vent system and termination.
• An inspection of the door gaskets to ensure a proper seal.
• An inspection of the burner, vent run, and primary air
openings.
• An inspection of the gas valve, gas components, and pilot
flame.
Cleaning
When the fireplace is first activated, there may be some smoking and
a visible film may be left on the glass. This is a normal condition, and
is the result of burning of protective coatings on new metal.
■ Glass must be cleaned periodically to remove any film (which
is a normal by-product of combustion) which may be visible.
Film can easily be removed by removing the door, as shown in
section. Handle the door carefully, and clean it with non-abrasive,
non-ammonia based glass cleaners. One of the most effective
products is Kel-Kem.
■ Use a vacuum cleaner or whisk broom to keep the control
compartment, burner, and firebox free from dust and lint.
Do not use ammonia based or abrasive cleaners on the glass, they will permanently
etch the surface. Use an approved gas fireplace glass cleaner such as Kel-Kem or
White off.
NOTICE
Maintenance
Procedure for Checking The Flue Gas Switch and
Thermal Switch
1). Remove the safety screen and outer glass, see appropriate
sections.
2). Disconnect the power vent harness from the plug in the control box.
3). Turn wall switch to 'ON' position.
4). Monitor the flue gas LED indicator for 2 minutes and ensure
that neither the LED indicator nor the ignitor illuminate. If LED
indicator or ignitor illuminates the flue gas switch is not functioning
properly. Disconnect the power to the unit, contact your technical
support representative.
5). Using a heat gun, warm up the heat sensor located between
two glass panels until heat sensor LED turns off.
6). Confirm LED resets within 10 minutes.
7). Reconnect power vent wire harness and reinstall the outer
glass panel and safety screen.
This fireplace has multiple power sources. Disconnect all power before servicing.
WARNING
Thermal Switch
Figure 34. Thermal Switch Location
