AML M2500 Decoder - Manual (Page 10)

6
Step 8: Verify that the cables are connected as shown below:
WAND
ORIGINAL
SYSTEM
CABLE
HOST
COMPUTER
SYSTEM
"TERMINAL"
CABLE
ASSEMBLY
"HOST" CABLE
ASSEMBLY
"HOST"
PORT
BAR CODE READER
ELECTRONICS UNIT
POWER
SUPPLY
"TERMINAL"
PORT
