AML M2500 Decoder User Manual
Page 48
44
MAG STRIPE OPTIONS #2
0) OUTPUT
This option designates which track(s) will be output, and in
what order. (To use a Dual Track decoder with a Single Track
application, select FIRST TRACK (only) or SECOND TRACK
(only)). Select one of the following:
0)
FIRST TRACK (only)
1)
SECOND TRACK (only)
2) *
BOTH (output in order)
3)
BOTH (REVERSE ORDER)
NOTE:
For a dual track (tracks 2&3) mag stripe
reader, FIRST TRACK represents track 2,
and SECOND TRACK represents track 3.
1) REQUIRE TWO TRACKS
ON
Two tracks of mag stripe data must be read for a
"good read" to occur. (Only for use with dual track
readers.)
OFF *
The decoder will accept one (or more) valid tracks as
a "good read".
NOTE:
THIS OPTION MUST BE OFF FOR ALL
SINGLE TRACK READERS. (Optional for dual
track readers.)
2) SEND START & END SENTINELS
(This option valid only if SEND ALL TRACK DATA is ON.)
ON *
The START/END SENTINEL characters for each
enabled track will be transmitted. The characters for
each type of sentinel are listed below:
1) Track 1 START SENTINEL =
" % "
2) Tracks 2 & 3 START SENTINEL =
" ; "
3) Tracks 1, 2, & 3 END SENTINEL =
" ? "
OFF
Do not transmit the START/END SENTINEL
characters.
