16
Step 2: The laser will begin scanning as soon as the bar code is brought
within 5 inches of the front of the laser. The red light on the back of
the LASER's handle will stay on as long as it is attempting a read.
The laser beam must cover the entire bar code label and part of
the blank area on both sides. Examples of bar code scans are
shown below:
Step 3: After a successful read the following will occur:
- The decoder will BEEP.
- The red light on the back of the laser will turn off.
- The green light on the back of the laser will turn on
for the duration of the decoder's beep.
- The bar code data is transmitted to the computer.
123456
123456
RIGHT
WRONG
