SLOT READER (Badge Reader)
Step 1: Hold the CARD so that the bar code label is on the bottom and
FACES the ARROW on the slot reader.
Step 2: Insert the CARD into the opening on either side of the reader.
Step 3: Holding the CARD flat against the bottom of the reader, SLIDE the
card through the opening. You can slide the CARD bi-directionally
(either left-to-right or right to left) and the data will output correctly
to your computer. The CARD must maintain contact with the base
of the reader while scanning. The front panel "POWER" light will
change to RED while the card is being pulled through the SLOT
READER.
NOTE: The center of the bar code must be positioned 0.5" from
the bottom edge of the card.
Step 4: After a successful read the following will occur:
- The reader will BEEP.
- The bar code data is transmitted to the computer.
Step 5: When the front panel "POWER" light changes to GREEN, the
reader is ready to scan another card.
VIDEO WORLD
ID CARD
837611
