42
MAG STRIPE OPTIONS #1
0) SEND ACCOUNT NUMBER
(This option valid only if option (3) below is OFF.)
ON * Transmit the ACCOUNT NUMBER data from the
magnetic card. On major credit cards, the account
number is available on TRACKS 1 & 2.
OFF Do not transmit the ACCOUNT NUMBER.
1) SEND NAME (TRACK 1 ONLY)
(This option valid only if option (3) below is OFF.)
ON * Transmit the NAME data from the magnetic card. On
major credit cards, the NAME is available only on
TRACK 1.
OFF Do not transmit the NAME.
2) SEND EXPIRATION DATE
(This option valid only if option (3) below is OFF.)
ON * Transmit the EXPIRATION DATE. On major credit
cards, the EXPIRATION DATE is available on
TRACKS 1 & 2.
OFF Do not transmit the EXPIRATION DATE.
3) SEND ALL TRACK DATA
ON * Transmit ALL the data from each enabled track. The
data is transmitted as it appears on the card with NO
formatting. However, SEPARATOR CHARACTERS
will be inserted between fields; see options (4) and
(6) for information on SEPARATOR CHARACTERS.
OFF Disables this option.
NOTE: If this option is ON, it overrides options (0), (1), (2), and (5).
4) ENTER TRACK 1 SEPARATOR CHARACTER
(This option valid only if option (3) is ON.)
The TRACK 1 SEPARATOR CHARACTER, which separates
the Track 1 fields, can be programmed by the user. Scan a
single character from the FULL ASCII section of the MENU.
The default is "^" (ASCII 94).
