AML M2500 Decoder User Manual
Page 22
18
Settings:
The following settings, which are the defaults, apply to this mode of
operation:
Laser/CCD Timeout
1-9 sec
Laser/CCD Trigger Shutoff
ON
Laser/CCD Continuous Run
OFF
CONTINUOUS SCANNING - REFLECTIVE SURFACE REQUIRED
Recommended Usage:
Recommended for most applications; a highly efficient mode. Note
that it is NOT recommended if the laser is constantly exposed to a
reflective surface, such as a white counter top.
Operation Description:
The laser will power ON when it is brought within 5 inches of a reflective
surface, and will continuously scan and read one bar code after
another, until pointed away from any reflective surface. When pointed
away from a reflective surface, the laser will continue to scan for the
number of seconds specified in the LASER/CCD TIMEOUT option (the
default is 1 second) before it shuts off.
RE-READS:
Accepts a re-read after the amount of time specified
in the CONTINUOUS RUN READ DELAY option (the
default is 1 second) has passed.
Settings:
The following settings apply to this mode of operation:
Laser/CCD Timeout
1-9 sec
Laser/CCD Trigger Shutoff
ON
Laser/CCD Continuous Run
ON
Continuous Run Read Delay 0.1-9.9 sec
For optimum "hands-free" performance, set the LASER/CCD
TIMEOUT option at 3-4 seconds.
