H3C Technologies H3C WX6000 Series Access Controllers - Manual (Page 125)

10-11
Outputting System Information to the Trap Buffer
The trap buffer receives only the trap information, and discards the log and debugging information even
if you have configured to output them to the trap buffer.
To do… Use the command… Remarks
Enter system view system-view —
Enable information center info-center enable
Optional
Enabled by default
Name the channel with a
specified channel number
info-center channel
channel-number name
channel-name Optional
See Table 10-2 for default channel
names.
Configure the channel
through which system
information can be output to
the trap buffer and specify the
buffer size
info-center trapbuffer [ channel
{ channel-number |
channel-name } | size buffersize ] *
Optional
By default, system information is output
to the trap buffer through channel 3
(known as trapbuffer) and the default
buffer size is 256.
Configure the output rules of
the system information
info-center source
{ module-name | default } channel
{ channel-number |
channel-name } [ debug { level
severity | state state } * | log { level
severity | state state } * | trap
{ level severity | state state } * ] *
Optional
See Default Output Rules of System
Information .
Configure the format of the
time stamp
info-center timestamp
{ debugging | log | trap } { boot |
date | none }
Optional
The time stamp format for log, trap and
debugging information is date by
default.
Outputting System Information to the Log Buffer
You can configure to output log, trap, and debugging information to the log buffer, but the log buffer
receives the log and debugging information only, and discards the trap information.
To do… Use the command… Remarks
Enter system view system-view —
Enable information center info-center enable
Optional
Enabled by default.
