Proc Amp
You adjust video levels using the Proc Amp effect. You use this effect either as
a standalone effect or in conjunction with the Resize or Key Shape effects.
You use four controls — Gain, Chroma, Setup, and Hue — to alter the entire
image or part of the video image.
One way to use the Proc Amp effect is to spotlight an image. You create a key
shape within a single track of video, check the Background checkbox, and
increase the Gain in order to bring out the spotlight within the video image.
Option
Range
Description
Gain
-100 to +100
-100 appears black and +100 washes out with brightness.
0 is the default.
Chroma
-100 to +100
-100 appears black and white while +100 boosts the color scheme. 0 is
the default.
Setup
-100 to +100
-100 crushes the black levels while +100 increases the brightness. 0 is
the default.
Hue
-180 to +180
The sweep from -180 to 180 cycles through the entire spectrum of
colors altering the image.
Invert
On or Off
Gives a film negative look to the image by inverting all of the colors
within the video image.
Background
On or Off
Within a Resize or Key Shape effect, lets you adjust the background
video layer.
