18 BFI/BF1051 / BGEN/es 2956
A delight in freshness
Only install the refrigerator/freezer in a stable
kitchen cabinet that has been properly aligned.
- Mount and fix the handles, depending on your
model and choice.
Figure 16: Installation with Ventilation Grille Set:
1. Screw the installation frame at the top (1) onto
the appliance (2).
2. Place the ventilation grille (3) on this, align it in
the center and secure at the front from
underneath.
3. Slide brackets (4) onto the side installation
frames (5) from above and below.
4. Using the frame (5), screw the brackets onto
the side wall*.
5. Slide the side installation frames (5) upwards
until they are in contact with the underside of
the ventilation grille.
6. Secure the side frames with the adhesive
section (7) to prevent them from sliding down.
Remove the protective film and affix the
adhesive sections over the upper brackets on
the handle and hinge sides.
R
EVERSING
D
OOR
H
INGES
Figure 16
LBR034
