24 BFI/BF1051 / BGEN/es 2956
3. Open the shut-off valve for the water supply
and check the entire water system for leaks.
Before the appliance is used for the first time a
licensed plumber should bleed air from the
system.
4. Insert the electrical plug for the combined
refrigerator/freezer into the electrical outlet
(Figure 23).
5. Move the combined refrigerator-freezer into
final position in the room.
Figure 23
A delight in freshness
I
CE
M
AKER
Connection to the Water Supply -
Figures 23, 24
1. Install the shut-off valve, water filter and
automatic shut-off device as required.
Note
The solenoid valve is located at the rear of your
unit.
2. The 1/4" copper tubing between the shut-off
valve and solenoid valve has a 3/4" male
connector
(Figure 24). Make sure there is
approximately 27" (70 cm) of excess tubing
behind the unit for easy connection.
Note
A 3/4" to a 1/4" adapter and cable clip are
supplied with the icemaker.
Remove the cover cap (4) from the solenoid
valve (1). Install the connection bracket (2) with
sealing ring (6) on the solenoid valve (1). Attach
the copper tube to the connection bracket (2).
Secure the copper tube (3) to the appliance
using the cable clip (5).
