Liebherr BF1051 - Manual (Page 21)

19 BFI/BF1051 / BGEN/es 2956
A delight in freshness
Figure 17
1 2
1
2 2
3
3
3
10 spanner
8 spanner
2
LBR035
- Figure 17: Connect the appliance to the
main power supply.
- If the appliance is equipped with an
IceMaker, establish the connection for the
water supply. See “IceMaker, Water
Connection”.
1. Carefully slide the appliance into the cabinet
until the ventilation grille touches the
surrounding kitchen cabinet.
2. Align the appliance until it is parallel with the
surrounding kitchen cabinet: at the front using
the leveling wheels (3) – take a 10 mm wrench;
at the rear using the adjusting bolt (2).
Maximum adjustment: 19/32” (15 mm).
I
NSTALLATION
3. Figure 18: Align the appliance at the side
with the cabinet side panel and attach it
with screws (1).
- Cover the screws with cover caps (2).
4. Fit the ventilation grille at the bottom [(3)
if the door is hinged on the left, (4) if it is
on the right]: Secure the ventilation grille
so that it touches the floor and then
adjust it using the slots.
Figure 18
LBR036
