22

BFI/BF1051 / BGEN/es 2956

A delight in freshness

Figure 21: Secure the refrigerator in place so it

does not tip forward when the fully stocked door
is opened.

2. Measure the distance from the floor to the

upper edge of the unit.

3. Locate and mark two wall studs (1) against the

wall where the refrigerator will be located. The
space between the unit top and the bottom
of the brackets must not be more than
1/4" (0.635 cm).

4. Make sure the screws (2) extend a minimum of

1" (2.54 cm) into each of the wall studs.

5. Make sure the anti-tip brackets (3) extend at

least 3" (7.62 cm) over the unit and are
securely in place.

B

LOCKING

F

OR

S

AFETY

IMPORTANT

The anti-tip brackets can be installed in either
direction or closer together. Always position
the anti-tip brackets as wide apart as
possible, but make sure they are anchored to
two studs.

6. Using the adjustable roller base, raise the unit

until it makes contact with the brackets. Make
sure the front levelers are firmly on the floor to
prevent appliance from tipping forward.

IMPORTANT

If your unit is positioned in between the wall
studs, a board can be secured to the wall.
Make sure the board is secured to the studs
with screws that will penetrate into the studs a
minimum of 1" (2.54 cm). The board should
be a minimum of 1" x 6" (2.54 cm x 15.24 cm)
and long enough to secure both ends to the
wall studs.

Figure 21

min 3"

1

2

3
