System 182 XT-4 Installation
3 - 49 ba76026e01 01/2012
Connection scheme of
the DIQ/JB
X1 X4 X2 X5 X3 X6 X7
Terminal strip
DIQ/JB SNCIQ(/UG)
SACIQ SACIQ
Sensor 2 Sensor 1
green
Shield / Filler stranded wire
black black
green
green
red
red
red
