Product overview
Technical Data
Technical Data EL9186 EL9187
Nominal voltage ≤ 60 V
DC
Current load ≤ 10 A
Diagnosis ­
Message to E­Bus ­
PE contact no
Shield connection ­
Renewed power feed yes
Outputs 8 (connected with positive power
contact) 8 x 0 V contact (connected with
negative power contact)
Current consumption from E­
Bus ­
Bit width in the process image 0
Electrical connection to
mounting rail ­
Electrical isolation ­
Side by side mounting on
EtherCAT Terminals with
power contact yes, left side without PE
Side by side mounting on
EtherCAT Terminals without
power contact yes
Configuration no address or configuration settings
Weight approx.. 60 g
Permissible ambient
temperature range (during
operation) ­25°C ... +60°C (extended temperature range)
0°C ... +55°C (according to cULus [
} 74] for Canada and USA)
0°C ... +55°C (according to ATEX [ } 71], see special conditions [ } 71])
Permissible ambient
temperature range (during
storage) ­40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [ } 60] on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068­2­6/EN
60068­2­27 conforms to EN 60068­2­6/
EN 60068­2­27, see Installation
instructions [
} 63] for enhanced
mechanical load capacity
EMC resistance burst/ESD conforms to EN 61000­6­2/EN 61000­6­4
Protect. class IP 20
Installation pos. variable, see chapter "Mounting of Passive Terminals [ } 70]"
Approval CE
ATEX [
} 71]
cULus [ } 74]
Connection EL9186
Terminal point Description
Indication No.
Output 1 ­ 8 1 ­ 8 Output 1 ­ 8 (internally connected with positive power
contact)
