Product overview

Terminal point

Meaning

Indication

No.

n.c.

1

not connected

+24 V

2

+24 V (internally connected with terminal point 6 and positive power
contact)

0 V

3

0 V (internally connected with terminal point 7 and negative power
contact)

PE

4

PE (internally connected with terminal point 8 and PE power contact)

n.c.

5

not connected

+24 V

6

+24 V (internally connected with terminal point 2 and positive power
contact)

0 V

7

0 V (internally connected with terminal point 3 and negative power
contact)

PE

8

PE (internally connected with terminal point 4 and PE power contact)

LEDs and connection EL9550

LED

Color

Meaning

Power­LED field

green

off

24 V

DC

 field supply not present

on

24 V

DC

 field supply present

Power­LED system

green

aoff

24 V

DC

 system supply not present

on

24 V

DC

 system supply present

Terminal point

Meaning

Indication

No.

Output +24 V

1

Output +24 V

+24 V

2

+24 V (internally connected with terminal point 6 and positive power
contact)

0 V

3

0 V (internally connected with terminal point 7 and negative power
contact)

Input +24 V

4

Input +24 V

Output 0 V

5

Output 0 V

+24 V

6

24 V (internally connected with terminal point 2 and positive power
contact)

0 V

7

0 V (internally connected with terminal point 3 and negative power
contact)

Input 0 V

8

Input 0 V
