Product overview
The HD EtherCAT Terminals (High Density) with increased packing density feature 16 connection points in
the housing of a 12 mm terminal block.
Technical Data
Technical Data EL9184 EL9188 EL9189
Nominal voltage ≤ 60 V
DC
Current load ≤ 10 A
Power LED ­
Error LED ­
Message to E­Bus ­
Shield connection ­
PE contact no
Renewed power feed yes
Outputs 2 x 8
(e.g.: 8 x 24 V contact, 8
x 0 V contact) 16
(e.g. 16 x 24 V contact) 16
(e.g. 16 x 0 V contact )
Current consumption from E­
Bus ­
Bit width in the process image 0
Electrical connection to
mounting rail ­
Electrical isolation ­
Configuration no address or configuration settings
Conductor types solid wire, stranded wire and ferrule
Conductor connection solid wire conductors: direct plug­in technique; stranded wire conductors and
ferrules: spring actuation by screwdriver
Rated cross­section solid wire: 0.08…1.5 mm²; stranded wire: 0.25…1.5 mm²; ferrule: 0.14…0.75
mm²
Weight approx.. 60 g
Permissible ambient
temperature range (during
operation) ­25°C ... +60°C (extended temperature range)
0°C ... +55°C (according to cULus [
} 74] for Canada and USA)
0°C ... +55°C (according to ATEX [ } 71], see special conditions [ } 71])
Permissible ambient
temperature range (during
storage) ­40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [ } 60] on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to
EN 60068­2­6/
EN 60068­2­27, see
Installation instructions
[
} 63] for enhanced
mechanical load
capacity
conforms to EN 60068­2­6/EN 60068­2­27
EMC resistance burst/ESD conforms to EN 61000­6­2/EN 61000­6­4
Protect. class IP 20
Installation pos. variable, see chapter "Mounting of Passive Terminals [ } 70]"
Approval CE
ATEX [
} 71]
cULus [ } 74]
