Product overview

Technical data

Technical data

EL9195

Technology

shield terminal, for dissipation of EMC interference

Power contact current load

max. 10 A

Power LED

­

Defect LED

­

Current consumption from E­Bus

­

Nominal voltage

arbitrary up to 230 V AC/DC

Integrated fine­wire fuse

­

Electrical isolation

­

Diagnosis

­

Reported to E­bus

­

Power contact

2 x power contact

PE contact

­

Shield connection

2 x

Electrical connection to mounting rail

yes

Bit width in the process image

­

Configuration

no address or configuration settings

Weight

approx. 50 g

Permissible ambient temperature range (during
operation)

0°C ... +55°C

Permissible ambient temperature range (during
storage)

­25°C ... +85°C

Permissible relative humidity

95%, no condensation

Dimensions (W x H x D)

approx. 15 mm x 100 mm x 70 mm (width aligned: 12
mm)

Mounting [

}

 60]

on 35 mm mounting rail conform to EN 60715

Vibration/shock resistance

conforms to EN 60068­2­6/EN 60068­2­27

EMC resistance burst/ESD

conforms to EN 61000­6­2/EN 61000­6­4

Protect. class

IP 20

Installation pos.

variable, see chapter "Mounting of Passive Terminals
[

}

 70]"

Approval

CE
ATEX [

}

 71]

cULus [

}

 74]

Connection EL9195

CAUTION

Hazard to individuals and devices!

When designing a Bus Terminal block with different potentials on the power contacts (e.g.
230 V AC and 24 V DC), please note that it is mandatory to use potential separation termi­
nals (EL9080)!
Bring the bus system into a safe, powered down state before starting installation, disas­
sembly or wiring of the Bus Terminals!

EL9xxx

34

Version 3.1
