CRS-200 COMTECH COMMUNICATIONS CORPORATION
CRS-200 REDUNDANCY SWITCH - OPERATIONS MANUAL PAGE 54
13 CABLE DRAWINGS
Figure 7 shows the cable required for a simple RS232 connection between a PC serial port
and the CRS-200 remore control port. This is needed for Flash upgrading.
The EIA-530 standard pinout (provided on the CRS-200) is becoming more popular in many
applications. However, there are still many occasions when, especially for existing
RS422/449 and V.35 users, a conversion must be made.
For these situations, Figure 8 and Figure 9 show cable drawings for EIA-530 to RS422/449
DCE conversion, and EIA-530 to V.35 DCE conversion.
Figure 10 shows the cable required to connect the TMIs and RMI to the modems.
