GAI-Tronics LE200, LE200-FSR, LE200-FLR Page/Party Line Extenders - Manual (Page 52)

Pub. 42004-701L2F
M ODEL LE200 S ERIES W ALL -M OUNT P AGE /P ARTY
®
L INE E XTENDERS P AGE 50 of 50
f:\standard ioms - current release\42004 instr. manuals\42004-701l2f.doc
04/09
Fiber Optic Transceiver
Nominal Voltage ........................................................................................................................... 12 V dc
Maximum Current .........................................................................................................................350 mA
Optical Port Type ..................................................................................................................................ST
Wavelength and Emitter Type
Model LE200-FSR.................................................................................................... 850 nm LED
Model LE200-FLR ............................................................................................... 1310 nm ELED
Range dB (km 1 )
Model LE200-FSR (62/125 µm cable) ..................................................................23 dB (6.7 km)
Model LE200-FLR (9/125 µm cable) .....................................................................32 dB (82 km)
N OTE : Distance based on 3 dB/km @ 850 nm and 1.5 dB/km @ 1310 nm for 62/125 µm fiber
Distance based on .35 dB/km @ 1310 nm for 9/125 µm fiber
Mechanical
Enclosure Material ............................................................................................................................ Steel
Unit dimensions ............................................ 24 H
× 20 W × 6.9 D inches (610 × 508 × 173 mm) nominal
Unit weight .....................................................................................................................................41 lbs.
Enclosure Environmental Rating ................................................................................................. NEMA 4
Environmental
Temperature range...............................................................................0° C to +50° C (+32° F to +122° F)
Relative humidity ............................................................................................10% - 85% non-condensing
Replacement Parts
Model Number Description
51701-029 Circuit Breaker, 15 A
51809-008 Fuse, 2 A
13118-011 Audio Terminal Connection Module
13118-012 I/O Terminal Connection Module
61214-007 DB25 Ribbon Cable Assembly
69443-002 Line Extender Main PCBA
40404-038 Power Supply, 12 V dc, 3.5 A, 45 W
GTRFP6019-005 Power Supply, 48 V dc, 2.5 A, 120 W
GTRFP6972-007 Digital T1 Modem, 850 Nm
GTRFP6972-009 Digital T1 Modem, 1310 Nm
GTRFP6972-021 Digital E1 Modem, 850 Nm
GTRFP6972-023 Digital E1 Modem, 1310 Nm
