Page 121
118
Audio
Setting items
Setting details
Stage Height
Adjust sound stage height
when using front height
speakers.
–10 – +10 (0)
• “Audyssey DSX®” can be set when you are using front height speakers
or front wide speakers.
• “Audyssey DSX®” is only valid when using a center speaker.
• “Audyssey DSX®” is valid when surround mode is DOLBY listening
mode or DTS listening mode other than PL
gz Height.
About Audyssey Dynamic Surround Expansion (A-DSX)
Audyssey DSX® is a scalable system that adds new speakers to
improve surround impression.
Starting with a 5.1 system Audyssey DSX® first adds Wide channels
for the biggest impact on envelopment. Research in human hearing has
proven that information from the Wide channels is much more critical
in the presentation of a realistic soundstage than the Back Surround
channels found in traditional 7.1 systems. Audyssey DSX® then
creates a pair of Height channels to reproduce the next most important
acoustical and perceptual cues. In addition to these new Wide and
Height channels, Audyssey DSX® applies Surround Envelopment
Processing to enhance the blend between the front and surround
channels.
Stage Width
Adjust sound stage width
when using front wide
speakers.
–10 – +10 (0)
Graphic EQ
Default settings are underlined.
Use the graphic equalizer to adjust the tone of each speaker.
“Graphic EQ” can be set when “MultEQ® XT” setting (
) is “Graphic EQ”.
Setting items
Setting details
Speaker Selection
Select whether to adjust
tones for individual speakers
or for all speakers.
All : Adjust the tone of all speakers together.
Left/Right : Adjust the tone of left and right speakers together.
Each : Adjust the tone of each speaker.
Adjust EQ
Adjust tones for each
frequency band. Adjust
the speaker selected in
“Speaker Selection”.
q
Select the speaker.
w
Select the adjustment frequency band.
63Hz / 125Hz / 250Hz / 500Hz / 1kHz / 2kHz / 4kHz / 8kHz / 16kHz
• Select the speakers you want to adjust when “Left/Right” or “Each”
is selected.
e
Adjust the level.
–20.0dB – +6.0dB (0.0dB)
Curve Copy
Copy “Audyssey Flat”
(
) curve from
MultEQ® XT.
Yes : Copy.
No : Do not copy.
• “Curve Copy” is displayed after “Audyssey® Setup” has been
performed.
• When you select “Curve Copy” and press
ENTER
, the “Copy “Audyssey
Flat”?” prompt is displayed. Select either “Yes” or “No”, and press
ENTER
.
Set Defaults
The “Graphic EQ” settings
are returned to the default
settings.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
When you select “Set Defaults” and press
ENTER
, the “Reset to the default values?”
prompt is displayed. Select either “Yes” or
“No”, and press
ENTER
.
