TASCAM DR-40
33
+ button:
Use this to move the cursor (the highlighted area) upward
on the screen, or increase values.
– button:
Use this to move the cursor (the highlighted area)
downward on the screen, or decrease values.
QUICK button:
This opens the Quick menu.
Stopped
• : current playback file deletion, division, level
alignment and mixdown functions
Playing back/playback control screen
• : level alignment
function
Recording standby
• : level control function, mic left-
right swapping function
A popup menu is turned on or off in the
BROWSE
screen or
PLAYLIST
screen.
Press when the
MIXER
screen is open to set the MS decoder.
REC MODE button
Opens the
REC MODE
screen.
When the
REC MODE
screen is open, returns to the Home
Screen.
MIXER button
Opens the
MIXER
screen.
When the
MIXER
screen is open, returns to the Home
Screen.
1/2 [SOLO] button
Opens a meter display that shows the 1/2 input level
setting status.
In DUAL or 4CH mode, press and hold during recording or
playback to solo channels 1/2.
3/4 [SOLO] button
Opens a meter display that shows the 3/4 input level
setting status.
In DUAL or 4CH mode, press and hold during recording or
playback to solo channels 3/4.
2 – Names and Functions of Parts
