Teac DR-40 - Manual (Page 98)

98
TASCAM DR-40
By connecting this unit with a computer using the USB cable,
you can transfer audio files on the SD card in the unit to a
computer, as well as transfer audio files on the computer to
the SD card in the unit.
This unit can handle audio files of the following formats.
MP3: 32 kbps - 320 kbps, 44.1 kHz/48 kHz
WAV: 44.1 kHz/48 kHz/96 kHz, 16/24 bit
USB
Mini-B USB plug
Computer
NOTE
When connected by USB and set to • STORAGE
, the other
functions of the recorder are disabled.
The unit should be connected directly with the computer
•
instead of via a USB hub.
Instead of using USB to connect the DR-40 and a computer,
•
you can also conduct the same operations by removing
the SD card from the DR-40 and connecting it directly to a
computer that has a built-in SD card slot or by using a card
reader.
When the unit is connected through USB after being turned
on, or when the unit is turned on after being connecting
through USB, the
USB SELECT
screen appears to choose
between bus power supply or data transmission through USB.
Use the + or − button to select
STORAGE
, and press the
ENTER/MARK button to connect the unit with the computer
for data transmission. The message of
USB connected
appears
in the display.
Make sure that the SD card is inserted properly.
NOTE
If the USB cable is connected to the unit when batteries has
been installed, the power is supplied from the USB port (USB
bus power prioritized).
11 – Connecting with a computer
