6RIWZDUH 'HVFULSWLRQ

If the documentation of the encoder is not immediately
available, the parameters required for further definition of
data transmission between the encoder and the IK 115 can
also be found using the corresponding programming
software:
First you must press the key and then
interrogate the corresponding text boxes and manually enter
them in the text boxes of the IK 115 software.
After all encoder parameters required to display the position
values been entered, click
.
Then the position value display can be activated through the
key.
