User’s Manual of WGSD-8020
166
than zero must be able to match this entry.
• Any: Any value is allowed ("don't-care").
•
IP Option Specify the options flag setting for this ACE.
• No: IPv4 frames where the options flag is set must not be able to match this
entry.
• Yes: IPv4 frames where the options flag is set must be able to match this entry.
• Any: Any value is allowed ("don't-care").
• SIP Filter Specify the source IP filter for this ACE.
• Any: No source IP filter is specified. (Source IP filter is "don't-care".)
• Host: Source IP filter is set to Host. Specify the source IP address in the SIP
Address field that appears.
• Network: Source IP filter is set to Network. Specify the source IP address and
source IP mask in the SIP Address and SIP Mask fields that appear.
• SIP Address When "Host" or "Network" is selected for the source IP filter, you can enter a
specific SIP address in dotted decimal notation.
• SIP Mask When "Network" is selected for the source IP filter, you can enter a specific SIP
mask in dotted decimal notation.
• DIP Filter Specify the destination IP filter for this ACE.
• Any: No destination IP filter is specified. (Destination IP filter is "don't-care".)
• Host: Destination IP filter is set to Host. Specify the destination IP address in the
DIP Address field that appears.
• Network: Destination IP filter is set to Network. Specify the destination IP
address and destination IP mask in the DIP Address and DIP Mask fields that
appear.
• DIP Address When "Host" or "Network" is selected for the destination IP filter, you can enter a
specific DIP address in dotted decimal notation.
• DIP Mask When "Network" is selected for the destination IP filter, you can enter a specific
DIP mask in dotted decimal notation.
„ ICMP Parameters
The page includes the following fields:
Object Description
•
ICMP Type Filter Specify the ICMP filter for this ACE.
• Any: No ICMP filter is specified (ICMP filter status is "don't-care").
• Specific: If you want to filter a specific ICMP filter with this ACE, you can
enter a specific ICMP value. A field for entering an ICMP value appears.
•
ICMP Type Value
When "Specific" is selected for the ICMP filter, you can enter a specific ICMP
value. The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP
