Current Link Speed Provides the current link speed of the port.
•
Configured Link Speed Select any available link speed for the given switch port. Draw the menu bar to
select the mode.
• Auto Speed - Setup Auto negotiation.
• 10 half - Force sets 10Mbps/Half-Duplex mode.
• 10 Full - Force sets 10Mbps/Full-Duplex mode.
• 100 half - Force sets 100Mbps/Half-Duplex mode.
• 100 full - Force sets 100Mbps/Full-Duplex mode.
• 1000 full - Force sets 10000Mbps/Full-Duplex mode.
• Disable - Shutdown the port manually.
•
Flow Control
When Auto Speed is selected for a port, this section indicates the flow control
capability that is advertised to the link partner.
When a fixed-speed setting is selected, that is what is used.
• Current Rx column indicates whether pause frames on the port are
obeyed.
• Current Tx column indicates whether pause frames on the port are
transmitted.
The Rx and Tx settings are determined by the result of the last Auto-Negotiation.
Check the configured column to use flow control.
This setting is related to the setting for Configured Link Speed.
• Maximum Frame Enter the maximum frame size allowed for the switch port, including FCS. The
allowed range is 1518 bytes to 9600 bytes.
• Excessive Collision
Mode
Configure port transmit collision behavior.
• Discard : Discard frame after 16 collisions (default).
• estart : Restart backoff algorithm after 16 collisions.
• Power Control The Usage column shows the current percentage of the power consumption per
port. The Configured column allows for changing the power savings mode
parameters per port.
• Disabled : All power savings mechanisms disabled.
• ActiPHY : Link down power savings enabled.
• Dynamic : Link up power savings enabled.
• Enabled : Link up and link down power savings enabled.
When set each port to run at 100M Full, 100M Half, 10M Full, and 10M Half-speed modes. The
Auto-MDIX function will disable.
