I N S T A L L I N G T H E U L T R A L I T E - M K 3 H Y B R I D H A R D W A R E
25
A TYPICAL ULTRALITE-MK3 HYBRID SETUP
Here is a typical UltraLite-mk3 studio setup. This
rig can be operated without an external mixer. All
mixing and processing can be done in the
computer with audio software. During recording,
you can use the UltraLite-mk3’s CueMix™ FX no-
latency monitoring to listen to what you are
recording via the main outs, headphone outs, or
any other output pair. You can control monitoring
either from the front panel or from the included
CueMix FX software.
S/PDIF
DAT deck
quarter-inch
analog outs
synthesizer
monitors
Figure 4-9: A typical UltraLite-mk3 studio setup.
headphones
Analog outputs (sends, stage
monitors, surround monitors, etc.)
MIDI IN
MIDI OUT
UltraLite-mk3
rear panel
mic
FireWire
or USB2
guitars (with or
without an amp)
Analog
returns
Compressor, reverb or other
analog outboard gear
PC
