C U E M I X F X
64
THE MIXES TAB
Click the Mixes tab (Figure 10-2) to gain access to
the UltraLite-mk3’s eight stereo mix busses. The
Mixes tab displays one mix bus at a time.
Viewing a mix
Choose the mix you wish to view from the mix bus
menu (in the Mixes tab itself, as shown in
Figure 10-2). The menu shows all mixes by name,
followed by the UltraLite-mk3 output pair to
which each bus master fader is currently assigned,
if any.
Naming a mix
Click the mix name at the top of the mix bus master
fader (Figure 10-2) to edit the name.
Assigning a mix bus output
Choose the desired output pair for the mix bus
from the bus output menu (Figure 10-2). The bus
output menu displays all current available
(enabled) UltraLite-mk3 output pairs. If a bus is
already assigned to an output pair, the bus name
appears next to the output pair name to indicate
that the output pair is already taken by a bus. Only
one bus can be assigned to any given output pair. If
you choose an output already assigned to another
bus, that bus output will become disabled.
Bus fader
The bus fader (Figure 10-2) controls the overall
level of the mix (its volume on its stereo output).
Use the individual input faders to the left to control
individual input levels.
Figure 10-2: The Mixes tab.
UltraLite-mk3
inputs
Mix bus 1
master
fader
Mic inputs Inputs grouped as
stereo pairs
Mixes
tab
Input name
Channel focus
Input pan section
Input fader
Scroll bar for input
channels
Bus output
Bus Reverb
send/return
Bus name
Bus fader
Bus mute
Bus level meter
Input mute/solo
Input level meter
Mix bus
menu
